Description

11-H1kVA (Long-run Model)

Power Capacity: 1kVA

1. Operating Mode:
Single-phase Input / Single-phase Output, True Online Double-conversion.

2. Applications:
Widely applied in government, finance, telecommunications, education, transportation, meteorology, broadcasting, commerce & taxation, healthcare, energy, and power utilities.

3. Product Features:

• True Online Double-conversion: Ensures maximum power protection.

• Microprocessor Control: Guarantees high reliability and system stability.

• Input Power Factor Correction (PFC): Optimizes energy efficiency.

• Output Power Factor Up to 0.9: Compatible with more critical loads.

• Wide Input Voltage Range (90V – 300V): Adaptable to unstable power grids.

• Frequency Converter Mode: Efficient 50Hz/60Hz frequency conversion.

• Generator Compatible: Works effectively with generator power sources.

• Advanced Monitoring: Optional SNMP card allows for seamless monitoring via USB or RS232.

• User-Friendly Display: Intuitive interface for easy operation and comprehensive status monitoring.

• ECO Mode: High-efficiency operation for energy saving.

• Emergency Power Off (EPO): Enhances safety for critical installations.

• DSP Technology: Features advanced Digital Signal Processing; includes a built-in maintenance bypass switch (optional).

• Smart Battery Charger Design: Optimized to extend battery life and enhance performance.

• Built-in Isolation Transformer (Optional): Provides extra electrical safety and noise filtering.

4. Technical Specifications

• For 1-3kVA UPS: Output power will be derated to 80% when set to CVCF (Constant Voltage Constant Frequency) mode, or when the output voltage is set to 208VAC.

• For 6/10kVA UPS: Output power will be derated to 60% when set to CVCF mode, and derated to 90% when the output voltage is set to 208VAC.

• *The above standard models do not currently support redundant parallel operation.

• *200/208/220/230/240VAC output is only applicable to long-run models.
